Jason Street Multifamily Meridian 105 Architecture

2018-07-08 13:00

架构师提供的文本描述。杰森街多家族项目打破了联排住宅类型的物理惯例。个人单位脚印垂直挤压三层楼,这在这种项目类型中的典型,然而,内部部分的建筑体积被移除,以创造外部梯田。
Text description provided by the architects. The Jason Street Multifamily project breaks the physical conventions of the townhouse typology.   Individual unit footprints are extruded vertically over three stories, as typical in this project type, however, internal portions of the ensuing building volume are removed to create exterior terraces.

这种方法与传统的丹佛联排别墅模式形成鲜明对比,后者将这些空间放置在建筑物顶部。由此产生的计划提供了与建筑内部直接相邻的室外空间,并能看到市中心的天际线,这与一个由狗屋比例的楼梯围护所组成的社区形成了鲜明的对比,它们可以进入很少使用的屋顶甲板。
This approach flies in contrast to the conventional Denver townhouse model which positions these spaces on top of the building. The resulting plan offers outdoor spaces with direct adjacencies to the building interior and views to the downtown skyline and brings contrast to a neighborhood dominated by doghouse-scaled stair enclosures accessing seldomly used rooftop decks.
 First Level Plan
一级计划
 Second Level Plan
二级规划
 Third Level Plan
三级规划
从外部看,该项目的各种外观增加了对街景的兴趣。一座两层楼高的日光浴室向南延伸,将光线吸收到每个住宅中。级别的入口定位在一个外部柱廊,提供与行人交通隔离,并提供隐私,毗邻的生活空间。
Externally, the varied façade of the project adds interest to the streetscape. A two-story solarium reaches out to the south and absorbs light into each residence. Grade level entries are positioned in an exterior colonnade providing separation from pedestrian traffic and offering privacy to the abutting living space.

在内部,下陷的厨房是集中的社会中心,允许空间在客厅和餐厅之间自由流动。该项目介绍了一个调色板的外部材料,具有触觉和真实的品质。不锈钢面板是由Meridian 105从当地一家钣金制造商的救助库存中采购的。
Internally, a sunken kitchen is the centralized social hub, allowing the space to flow freely between the living and dining rooms. The project introduces a palette of exterior materials with tactile and authentic qualities. The stainless steel panels were procured by Meridian 105 from a local sheet metal fabricator’s salvage stock.

建筑材料质优价廉的特点,反映了设计团队对建筑发展的可持续发展。雪松壁板包裹柱廊是经过处理的松木焦油,选择其半透明的质量和长期保存的能力。
The rustic and imperfect quality of the material contributes to the character of the building and reflects the design team’s sustainable approach to building development. Cedar siding wrapping the colonnade is treated with a pine tar finish, chosen for its semi-transparent quality and aptitude for long-term preservation.


























Architects Meridian 105 Architecture
Location Denver, United States
Architect Team Chad Mitchell, Daniel Lipscomb
Area 10350.0 m2
Project Year 2018
Photographs Astula
Category Houses
